산업 현장의 생산 공정중 제품의 품질 및 생산성
확보 측면과 전산 SYSTEM실 및 실험실 등의 고정밀 기기를 취급하는 장소에서 사용기기 운전상태를 최적 조건으로 유지시켜
주면서 근무 인원의 업무 능률 향상을 위하여 실내를 년중 공기조화의 제반 조건을 만족토록 하는 것을 목적으로 합니다. |
|
 |
- 초에너지 절약형으로 설계되었으며 경제성에서
월등히 유리합니다.
- 온/습도가 자동적으로 정밀 유지 됩니다.
- 소음 진동이 적은 소형 SIROCCO FAN을 적용합니다.
- 외관이 미려하고 크기가 COMPACT합니다.
- 최신형 가습기를 사용합니다. |
|
 |
| - 공냉식(AIR
COOLED SYSTEM) TYPE |
| Description |
unit |
HH030AD |
HH050AD |
HH075AD |
HH100AD |
HH150AD |
HH200AD |
| COOLING
CAPACITY |
kal/h |
8,400 |
14,000 |
21,000 |
28,000 |
42,000 |
56,000 |
| HEATING
CAPACITY |
kal/h |
6,880 |
8,600 |
10,320 |
13,460 |
17,200 |
20,640 |
| HUMIDIFIER CAPACITY |
L/h |
2.4 |
3.6 |
6 |
7.2 |
9.6 |
12 |
| DIMENSION
(UP FLOW TYPE) |
mm |
650×1000×1700 |
750×1000×1800 |
800×1300×1800 |
800×1450×1950 |
850×1800×2100 |
900×2200×2200 |
| DIMENSION
(DOWN FLOW TYPE) |
mm |
750×1100×1600 |
750×1300×1700 |
800×1450×1800 |
800×1500×1850 |
850×2100×2100 |
900×2200×2100 |
| POWER
SUPPLY |
AC
3￠ 220/380/440V 60㎐ |
| EVAPORATOR |
MULTI-PASS CROSS FINNED TUBE TYPE |
| BLOWER(TYPE)
(MOTOR)
(AIR VOLUME)
(STATIC PRESS.) |
|
#13/4DS |
#2DS |
#13/4×2DS |
#2DS×2 |
#21/2DS×2 |
#21/2DS×2 |
| kW |
0.2×8P |
0.75×8P |
0.2×2×8P |
0.75×2×8P |
0.75×2×8P |
0.75×2×8P |
| CMM |
33 |
55 |
82 |
110 |
165 |
220 |
| mmAq |
15
~20 |
| AIR
FILTER |
KPS
- 6000N |
| HEATER |
ELECTRIC
AERO FIN TYPE |
| kW |
8 |
10 |
14 |
16 |
20 |
24 |
| STEP |
2 |
4 |
4 |
4 |
4 |
4 |
| HUMIDIFIER |
ELECTRIC
FAN TYPE |
| kW |
2 |
3 |
5 |
6 |
8 |
10 |
| STEP |
1 |
1 |
2 |
2 |
2 |
2 |
| REFRIGERANT |
R
- 22 |
| CONTROL |
THERMAL
EXPANSION VALVE |
| PIPE |
A |
25 |
32 |
40 |
40 |
50 |
66 |
| SIZE(SUCTION) |
|
|
|
|
|
|
|
| (LIQUID) |
A |
25
|
32
|
40
|
40
|
50
|
65 |
| (HUMIDIFIER WATER INLET) |
A |
15 |
15 |
15 |
15 |
15 |
15 |
| (DRAIN) |
A |
25 |
25 |
25 |
25 |
25 |
25 |
| Power |
KW |
9.78 |
15.86 |
24.69 |
31.88 |
44.08 |
53.63 |
| Weight
|
KG |
380 |
420 |
580 |
740 |
900 |
1050 |
| KG |
550 |
700 |
850 |
980 |
1150 |
1300 |
|
| - 공냉식(AIR
COOLED SYSTEM) CONDENSING UNIT |
| Description |
Unit
|
HH30ACDU |
HH50CDU |
HH75CDU |
HH100CDU |
| COMPRESSOR |
TYPE
|
HERMETIC
RECIPROCATING |
| CAPACITY |
kW
|
2.2
|
3.75
|
5.5
|
7.5
|
| CRANKCASE
HEATER |
W
|
40
|
40
|
40
|
40
|
| FAN
|
TYPE
|
DIRECT
DRIVE PROPELLER TYPE TAN |
| AIR
VOL |
CMM
|
75
|
120
|
175
|
230
|
| FAN
MOTOR |
kW
|
0.38(1/2HP) |
0.38(1/2HP) |
0.38××
|
××
|
| SIZE
|
mm
|
￠500
|
￠500
|
￠500×2
|
￠500×2 |
| CONDENSOR |
TYPE
|
6.66
|
MULTI
- PASS CROSS FINNED TUBE TYPE |
| FACE
AREA |
m²
|
0.75
|
0.8
|
1.05
|
1.38
|
| DIMENSION |
mm
|
990×820 |
1000×1020 |
1100×1300
|
1200×1400 |
| 6.66
|
×700
|
×670
|
×690
|
×690
|
| PIPE
SIZE |
SUCTION |
A
|
15
|
20
|
25
|
30
|
| LIQUID |
A
|
10
|
15
|
20
|
20
|
|
| - 수냉식(WATER
COOLED SYSTEM) / 그리콜식(GLYCOL COOLED SYSTEM) CONDENSING UNIT
|
| Description |
Unit |
HH030WD |
HH050WD |
HH075WD |
HH100WD |
HH150WD |
HH200WD |
| COOLING
CAPACITY |
Kal/h |
8,400 |
14,000 |
21,000 |
28,000 |
42,000 |
56,000 |
| HEATING
CAPACITY |
Kal/h |
6,880 |
8,600 |
10,320 |
13,460 |
17,200 |
20,640 |
| COOLING
CAPACITY
(GLYCOL) |
Kal/h |
8,400 |
14,000 |
21,000 |
28,000 |
42,000 |
56,000 |
| HEATING
CAPACITY(GLYCOL) |
Kal/h |
6,880 |
8,600 |
10,320 |
13,460 |
17,200 |
20,640 |
| HUMIDIFIER CAPACITY |
L/h |
2.4 |
3.6 |
6 |
7.2 |
9.6 |
12 |
| DIMENSION |
mm |
700×1100×1700 |
700×1100×1700 |
700×1100×1750 |
850×1650×2000 |
950×1900×2100 |
950×2200×2300 |
| POWER
SUPPLY |
AC
3￠220/380/440V 60㎐ |
| EVAPORATOR |
MULTI
- PASS CROSS FINNED TUBE TYPE |
| BLOWER |
TYPE |
|
# |
# |
# |
# |
# |
# |
| MOTOR |
kW |
0.2×8P |
0.75×8P |
0.2×2×8P |
0.75×2×8P |
0.75×2×8P |
0.75×2×8P |
| AIR
VOLUME |
CMM |
33 |
55 |
82 |
110 |
165 |
220 |
| STATIC
Press. |
mmAq |
15
~ 20 |
| AIR
FILTER |
KPS
- 6000N |
| HEATER |
ELECTRIC
AERO FIN TYPE |
| motor |
kW |
8 |
10 |
14 |
16 |
20 |
24 |
| Expansion
Coil |
STEP |
2 |
4 |
4 |
4 |
4 |
4 |
| Humidifier |
ELECTRIC
FAN TYPE |
| kW |
2 |
3 |
5 |
6 |
8 |
10 |
| STEP |
1 |
1 |
2 |
2 |
2 |
2 |
| REFRIGERANT |
R-22 |
| CONTROL |
THERMAL
EXPANSION VALVE |
| PIPE
SIZE |
SUCTION |
A
|
25 |
32 |
40 |
40 |
50 |
65 |
| LIQUID |
A |
25 |
32 |
40 |
40 |
50 |
65 |
| HUMIDIFIER WATER INLET |
A |
15 |
15 |
15 |
15 |
15 |
15 |
| DRAIN |
A |
25 |
25 |
25 |
25 |
25 |
25 |
|
| - 수냉식(WATER
COOLED SYSTEM) / 그리콜식(GLYCOL COOLED SYSTEM) CONDENSING UNIT
|
| Description |
Unit |
HH30WCDU |
HH50WCDU |
HH75WCDU |
HH100WCDU |
HH150WCDU |
HH200WCDU |
| FAN
(TYPE) |
GLYCOL
DRY COOLED TYPE TAN |
| AIR
VOL |
CMM |
150 |
180 |
224 |
300 |
450 |
600 |
| FAN
MOTOR |
kW |
0.4 |
0.4
× 2 |
0.75 |
0.4
× 2 |
0.75
× 2 |
1.5
× 2 |
| Parts |
GLCOL
COIL PROPELER FAN(4-BLADE) CIR.PUMP EXPA.TANK |
| Power |
kW |
17.9 |
22.7 |
26.75 |
36.5 |
47.25 |
59.6 |
|
| - Specification
of cooled dehumidifier |
| Description |
Unit |
HH030DH |
HH050DH |
HH075DH |
HH100DH |
HH100DH |
HH200DH |
| COOLING
CAPACITY |
tiKal/h |
8,400 |
14,000 |
21,000 |
28,000 |
42,000 |
56,000 |
| HEATING
CAPACITY |
Kal/h |
6,880 |
8,600 |
10,320 |
13,460 |
17,200 |
20,640 |
| DIMENSION |
mm |
900x600 |
1200x670 |
1300x750 |
150x900 |
1900x100 |
2100x1200 |
| |
x2200 |
x2400 |
x2500 |
x2600 |
x2700 |
x2800 |
| POWER
SUPPLY |
AC
3ø220/380/440V 60Hz |
| EVAPORATOR |
MULTI
- PASS CROSS FINNED TUBE TYPE |
| FAN
(TYPE)MOTORAIR VOLSTATIC PRESURE |
|
#13/4DS |
#2DS |
#13/4x2DS |
#2DSx2
|
#21/2DSx2 |
#21/2DSx2 |
| kW |
0.2x8P |
0.75x8P
|
0.2x2x8P |
0.75x2x8P |
0.75x2x8P |
0.75x2x8P |
| CMM |
33 |
55
|
82 |
110
|
165 |
220 |
| mmAq |
40~50 |
| PRE
FILTER |
% |
50t
N.B.S 85% |
|
|
 |
|
|
